The Zetin box-type sintering furnace adopts a classic door-opening design, with precise temperature control, uniform internal temperature in the chamber of furnace, and good sealing performance.
-
Features
- The unique safety lock design effectively prevents the sintering failure caused by opening the furnace door by mistake during the sintering process;
- Compact chamber, 80 units can be sintered at most at a time；High-purity dental silicon molybdenum heating element, non-pollution
- PID intelligent temperature control system ensures the high temperature control accuracy. The actually temperature error at ±1℃; Can Store 40 Programs.
- 7-TFT touch screen can fully display all the operations, so very easy to set up the program, friendly human-machine interface.
- Longer service life Insulation materials with good thermal insulation effect ensures a uniformity temperature circumstance
- With power-off memory function, it can start working from any phase of any program.
Technical Parameters
| Max.Temperature |
1730℃ |
| Temperature control accuracy |
±1℃ |
| Touch screen |
7" TFT |
| Power Output |
3 KW |
| Electrical connected value |
220 50/60 HZ ＆ 110 V 50/60 HZ |
| Heating element |
High purity heater specially for dentistry |
| Sensor |
Type B |
| Capacity |
Ø 110 ×120 mm |
| Conventional sintering program |
No.1 |
| Cleaning program |
No.40 |
| Program |
Stored 40 programs ,with power-off memory function |
| Size (L*W*H) |
450× 500×850 mm 3 |
| Net weight |
60 KG |
